Neuer Zunhammer SKE18,5PU Gülleverteiler

Preis: Price on Application
Illumination
Air Brakes
Leveler
Hyd. Linkage Operation
Steering Axle
Load Sensing
Tyre Pressure Control System
Tandem
SKE18.5PU
(0010) Zunhammer pump tanker
(0020) Pump tanker SKE18,5PU with three-point hitch
(0030) (professional class)
(0040) TANK
(0050) heart-shaped polystyrene tank 18500 ltr
(0060) with 3 baffles
(0070) Angled support
large wheel recesses
(0080) hinged lid with hinge and
(0090) Lever screws closed
(0100) Float indicator front stainless steel with
(0110) Fiber rod
(0120) FRAME CHASSIS
(0130) high-quality steel frame inside and
(0140) hot-dip galvanized on the outside
(0150) torsion-resistant hollow section
(0160) cross members at the front and
(0170) at the rear
(0180) patented ECO design with
(0190) pressure line through the
(0200) chassis beam ( space and weight
(0210) saving )
(0220) Bottom hitch with height-adjustable
(0230) drawbar
(0240) bolted towing eye for KUGEL mount
(0250) 80mm
(0260) Automatic drawbar with pneum. valves
(0270) drawbar load 3000 kg
(0280) hydraulic folding support leg
(0290) single-acting
(0300) AXLE
(0310) Tandem unit with air suspension and
(0320) Preparation for tire pressure regulation system
(0330) second axle with self-steering
(0340) Steering in steering knuckle
(0350) all axles individually bolted in
(0360) 10cm grid on the frame
(0370) adjustable
(0380) the front axle is optionally available with
(0390) axle lift possible
(0400) Brake drum 410x180 BPW
(0410) with S-cam brake permissible up to 50km/h
(0420) all 4 axle beams individually with
(0430) diaphragm brake cylinder
(0440) single-acting hydraulic steering lock
(0450) to the tractor
(0460) 2-wire air brake WABCO with
(0470) ALB regulator on the float
(0480) WHEELS
(0490) 4 wheels 28L26 Alliance block profile on
(0500) 10-hole rim
(0510) h=159cm
w=71cm
(0520) PUMP
(0530) rotary lobe pump VX184Q Vogelsang with
(0540) hiflo piston
(0550) Quick service immediately accessible from the rear
(0560) immediately accessible
(0570) Locking chamber with pressurized
(0580) oil filling
(0590) Capacity: 4,300 liters at 600 rpm
(0600) Pressure up to 8 bar permissible
(0610) PUMP SYSTEM
(0620) Suction-side outlet sump in front
(0630) Bottom third with
(0640) Maintenance cover
tank line NW159 to
(0650) Three-way valve
(0660) Three-way valve on suction side NW159
(0670) pneumatically actuated
(0680) Automatic limit switch-off or switching by
(0690) push button
(0700) left side suction side quick coupler
(0710) NW159 with air tap
(0720) Pressure-side line in chassis
(0730) integrated larger NW150
(0740) rear three-way valve NW150 hydraulic
(0750) double-acting for
(0760) Function: Drum filling - stirring - (0770) Distributing
(0770) distribution
(0780) ELECTROMAGNETIC CONTROL BLOCK
(0790) Magic box for operating the
(0800) hydraulic system with only
(0810) one tractor connection ew and return
(0820) There are 24 push buttons on the display
(0830) are available on the display
(0840) The following functions are assigned
(0850) Rear slider open - closed
(0860) Three-point open - down
(0870) Three-point float position
(0880) Fixed position
(0890) Fold linkage out - in
(0900) Oil motor runs with this connection
(0910) A separate control unit is required for the steering axle
(0920) control unit is required for the steering axle
(0930) DISTRIBUTOR
(0940) Three-point mounting at the rear of the
(0950) Vehicle frame Cat. II/III
(0960) hydraulically height-adjustable
(0970) Swing position or fixed height
(0980) adjustable
(0990) Rear bucket connection 108
(1000) Attachments > 3,000 kg at the coupling point
(1010) require approval from Zunhammer
(1020) Please order distributor separately !
(1030) ACCESSORIES
(1040) 2 large wheel chocks
(1050) 3-chamber lighting system with
(1060) Splash guard hoods
(1070) Pressure relief bottle for return flow
(1080) APPROVAL
(1090) standard incl. TÜV approval 25km/h
(1100) (operating license)
(1110) Letter 40km/h only possible with mudguard
Kontaktdaten anzeigen
(1130) ID no.: A.1.2.119 in the positive list
(1140) Investment program Landoppelt wirkendirtschaft in
(1150) Germany
(1160) Glide-Fix distributor 15m
(1170) with 2 cutting heads 30+30
(1180) with 60 glide feet = distance 25cm
(1190) stable spring-loaded hose guides
(1200) with TOP-DROP-STOP by tilting the boom
(1210) boom
(1220) hydraulic folding boom
(1230) outlets stand upwards during transportation
(1240) upwards during transport
(1250) Complete boom hot-dip galvanized
(1260) Pre-assembled for attachment to the tanker
(1270) Warning signs with LED lighting
(1280) Connecting hose with 2x swivel joints
(1290) and 2x brass wedge gate valve by hand
(1300) Universal coupling at the rear as Bauer
(1310) Cup NW108
(1320) Hydraulic connections 1 x double-acting for folding
(1330) and ew+double-acting for
(1340) Oil engines required
(1350) without mounting material on the vehicle
(1360) Our joystick control is required as an
(1370) Accessories required
(1380) For retrofitting
(1390) The hydraulic hoses end at the
(1400) center frame
Kontaktdaten anzeigen
(1420) Four-point frame MK tank console
(1430) suitable for three-point hitch cat. III
(1440) for the upper support on the rear tank
(1450) attached
(1460) Parts galvanized
(1470) for tow hose attachment Folding to the front
(1480) at the front
Kontaktdaten anzeigen
(1500) Three-point four-point frame for 12/15 m
(1510) FF
SS
GLF 1.211.00.03.00.000
(1520) hot-dip galvanized
Kontaktdaten anzeigen
(1540) Glidefix pendulum slope compensation
(1550) centrally suspended
(1560) Automatic floating working position
(1570) Surcharge
Kontaktdaten anzeigen
(1590) Exacut-ECQ surcharge EX30 DN40
(1600) per distributor head
Kontaktdaten anzeigen
(1620) Width cut-off hydraulic tipping distributor
(1630) Half width
optional left/right open
(1640) Attention
(1650) 1 x additional valve per side in the
(1660) control unit required
(1670) Operating control unit requires one
(1680) free space
Kontaktdaten anzeigen
(1700) Additional valve electromagnetically controlled
(1710) optionally double-acting or ew for function
Kontaktdaten anzeigen
(1730) ISOBUS control for direct control
(1740) from the tractor ( ISO-BUS terminal)
(1750) - replaces joystick with Gülle2000
(1760) Display of current cbm/ha during spreading
(1770) Spreading
(1780) Totalization of ha
cbm
and hours
(1790) Display of fill level
(1800) Speed and PTO rpm
(1810) comes from the tractor
(1820) Terminal on the tractor is necessary
Kontaktdaten anzeigen
(1840) ISOBUS extension 1 for functions
(1850) Tip folding
slope compensation
(1860) with additional valve
4-point linkage
(1870) Section with CFC valves: 3-fold
(1880) shut-off + tramline
(1890) left and right side switch
(1900) together
(1910) CFCs can be used with additional extension
(1920) 3 independent
(1930) switching
Kontaktdaten anzeigen
(1950) Load-sensing hydraulic block
surcharge
(1960) on standard control block
Kontaktdaten anzeigen
(1980) Work light LED 3100 lumen 12V
(1990) incl. mounting on tanker and switch
(2000) incl. wiring
(2010) attached
(2020) - center right - center left
(2030) Particularly strong luminosity!
Kontaktdaten anzeigen
(2050) Bottom hitch 4 tons instead of 3 tons
Kontaktdaten anzeigen
(2070) Air suspension 14 to axles for STS,SK
(2080) Surcharge for 12-ton air suspension
(2090) Not permitted in conjunction with
(2100) Outer width 2550 mm
(2110) The road traffic axle load
(2120) remains at 10 tons
(2130) incl. RDS preparation
Kontaktdaten anzeigen
(2150) Single hydraulic drawbar suspension
(2160) with diaphragm accumulator
(2170) only in conjunction with bottom hitch
(2180) Suspension
(2190) incl. hydraulic height adjustment from the tractor
(2200) from tractor
Kontaktdaten anzeigen
(2220) Additional valve
electromagnetically controlled
(2230) optionally double-acting or ew for function
Kontaktdaten anzeigen
(2250) Electric forced steering for tandem GTW
(2260) Linkage point next to drawbar eye
(2270) of the steering movement through steering angle measurement
(2280) on towing ball
(2290) the vehicle steers forwards and
(2300) backwards
(2310) very precise steering with
(2320) emergency running properties
(2330) = TÜV-approved
(2340) no steering lock required at higher
(2350) speed necessary
(2360) Loadsensing is required see
Kontaktdaten anzeigen
(2380) Tractor must also have load sensing
(2390) one patent lever included
(2400) included for 1 tractor
Kontaktdaten anzeigen
(2430) Complete wheel 10-hole ET + 30
(2440) -> Outer width 3m
Kontaktdaten anzeigen
(2460) Mudguard tandem aluminum from 800-26.5 or
(2470) 28L26 or 750-30.5
Kontaktdaten anzeigen
(2490) Mud flap rear mudguard
(2500) with mounting
Kontaktdaten anzeigen
(2520) Lubrication strip for tandem axle unit
(2530) 1x left and 1x right
(2540) with brake shafts
Kontaktdaten anzeigen
(2560) Tire pressure control system 1-wire tandem
(2570) with screw compressor 3200Ltr/min
(2580) Pneumatic control box/road/field position
(2590) Pressure each
(2600) individually preselectable
(2610) shut-off valves
Kontaktdaten anzeigen
(2630) Additional valve electromagnetically controlled
(2640) optionally double-acting or ew for function
Kontaktdaten anzeigen
(2660) Fully automatic computer with hydrostatic pump control
(2670) pump control incl. hydraulics
(2680) Control valves
cabling
test run
(2690) incl. pump transverse installation
(2700) without central computer
(2710) without ISOBUS
Kontaktdaten anzeigen
(2730) Pump VX260Q Inj. modular instead of VX184Q
(2740) with radial protection plate and lubrication center
(2750) Bar center
incl. double-actingH suction side
(2760) NW200
(2770) Pump capacity 5430 liters at 540 rpm
Kontaktdaten anzeigen
(2790) Rotacut 10000 with angular stone trap box
(2800) Hinged door for emptying
(2810) Connection bends and mounting
(2820) with mounting bracket
(2830) all 8"
(2840) incl. changeover valve or additional valve
(2850) -->> Always include operating instructions for RIGHT direction of travel!
(3270) (1-971-11-0003
included in the
(3280) price included)
(3290) Adaptation costs for retrofitting and
(3300) third-party vehicles
(3310) are not included in the price and will be
(3320) separately
(3330) separately
Kontaktdaten anzeigen
(3350) TRISTA or ZASTA - hopper station
(3360) Surcharge 12V
(3370) instead of 230V with gel battery with high
(3380) cycle stability
incl. charge level indicator
(3390) and charger
Kontaktdaten anzeigen
(3410) Radio remote control for hopper station
(3420) with pneumatic valve (GTW equipment)
(3430) integrated in the limit switch pn
(3440) or hydraulic
(3450) - Stationary transmitter
installed on GTW
(3460) - Cabling incl. time control
(3470) Function
(3480) When the drum is full
the
(3490) hopper station closes first
then
(3500) switches the three-way valve
(3510) on the GTW switches to stirring
Kontaktdaten anzeigen
(3530) Hopper station drain hose NW102
(3540) for high-low tank with
(3550) Perrot M-part 108/102 galvanized
Kontaktdaten anzeigen
(3570) Pressure gauge up to - 1 bar
(3580) for suction side pump
Kontaktdaten anzeigen
(3600) Pressure gauge up to 10 bar
(3610) for pressure side pump
Kontaktdaten anzeigen
(3630) Pressure connection for ECO-GTW NW159 with
(3640) Quick coupler and manual slide valve
(3650) Always mounted opposite the suction side
(3660) Also suitable as a pump-over connection
(3670) available
(3680) Screwed towing eye incl. mounting
(3690) (ratchet rail) 1.000.30.00.00.090
Kontaktdaten anzeigen
(3710) Suction hose transport bracket
(3720) for 5m hose - NW150
Kontaktdaten anzeigen
(3740) PTO shaft WW with SB coupling for
(3750) VX 186/184-260
Kontaktdaten anzeigen
(3770) Attachment GlideFix 15m drum incl
(3780) Transport bracket and supports NETTO
Kontaktdaten anzeigen
(3800) TÜV certificate 40km/h net
(3810) only for ECO tanker
(3820) Driving direction left
Kontaktdaten anzeigen
Kontaktdaten anzeigen
1-circuit system with
40km/h
Docking ball NW200
incl. control line
and hydraulic
transmission
